The main differences between the Cor Vision and Cor Vision Plus sliding door systems by Cortizo revolve around size, glazing options, thermal performance, and functionality.
Size and Capacity
Cor Vision: These doors can accommodate panels up to approximately 3 meters high and 2.5 meters wide. The maximum weight capacity for each sash is 400 kg.
Cor Vision Plus: This model supports larger panels, up to 4 meters high and 4 meters wide, with a maximum weight capacity of 700 kg for motorised operation or 400 kg for manual operation.
Glazing
Cor Vision: It supports double glazing with a maximum glass thickness of 30 mm.
Cor Vision Plus: This model supports triple glazing with a maximum glass thickness of 54 mm, which provides better thermal and acoustic insulation.
Thermal Performance
Cor Vision: Has a U-value (a measure of thermal insulation) of approximately 1.3 W/(m²K).
Cor Vision Plus: Offers improved thermal performance with a U-value of about 1.1 W/(m²K) due to the possibility of using triple glazing.
Sightlines
Cor Vision: Features a slim 20mm mullion (the vertical bar between panes of glass).
Cor Vision Plus: Slightly larger sightline at 25mm, providing a robust structure for larger glass panels.
Functionality and Features
Cor Vision: Available with manual sliding mechanisms.
Cor Vision Plus: Can be equipped with motorised sliding mechanisms, making it more convenient for larger and heavier panels. It also integrates better with smart home systems for automated operation.
Conclusion
Overall, the Cor Vision Plus offers enhanced features for larger openings, better thermal performance, and the convenience of motorised operation, making it suitable for modern, high-specification architectural projects.
The standard Cor Vision remains a highly effective solution for smaller applications or replacements of existing patio doors.
